C228 Island Self Service Sneeze Guards


Overview:
  The C228 self-serve sneeze guard is stylish and practical. This style has front shield at a 45° slope and a center top shelf. The C228 is used on straight counters. The bay size can be as small as 24" or as large as 84". The large bay size makes it possible to straddle most any drop-in. The C228 with closed ends provides the maximum display space.
Examples:

  C228 Single Bay
  C228 Deep Double Bay with shelf
  C228A Curved Triple Bay
  C228 Double Bay Sculptured Center
  C228 Single Bay - Deep Shelf
C228A Curved Triple Bay
C228-Island Sneeze Guard
Click Image Cut Sheet
C228 Double Bay (Closed ends)
(84 in. max bay size)
Support Styles:
  The C228 sneeze guards have five standard supports styles made from 1/2" Clear or Crystal Clear safety glass. The "Open", "Front" and "Sculptured" supports are generally used as interior support.. The "Closed", "Closed-Var" used as end supports.
Edge Sculpture Closed
Edge Sculpture Closed
Open Edge Closed Insert Closed-Var
Open   Closed-Var
NSF Certified when Deep or Extended end supports are used
Upgrades:

Radius Corners
  3/8" Crystal Clear
  Carved Glass Designs / Logo

Specialty Units:
  Model C228 can be equipted with our low profile super bright LED lights. It works best with dual arrays.
90° outside Corner
90° inside corner
360° ends
45° inside corner
Design Center
  C228-Single Bay (24" to 84" wide)
  C228-Single Bay (48" to 168" wide)
  Consult customer service for custom sizes or larger configurations.
Add-Ons

  LED Lights
  Food Warmers

Glass Divider -1990 Hartog Dr. San Jose, CA 95131 Voice: (408) 844-8335 Fax: (408) 988-4423 Service@glassdivider.com
